EcoFlow Power Kits 5kVA 48V Power System - 5kWh

EcoFlow 5kVA 48V Power System is a fully integrated, plug and play power solution for vans, motorhomes, RVs, and off grid builds, combining high output power, expandable LFP battery storage, multiple charging methods, and smart system control.

Key Features:

• Fully integrated, plug and play 5kVA 48V power system for vans, motorhomes, and RVs
• Up to 4000W output and 8000W surge power for high demand appliances
• Runs up to two 13,500 BTU RV air conditioners at the same time
• Expandable 5kWh to 45kWh LFP battery capacity with stackable batteries
• Four charging methods: shore power, solar, vehicle alternator, and Smart Generator input
• Up to 4800W solar input for fast off grid charging
• Up to 6000W alternator input when connected to the original and second alternator
• Up to 4000W shore power charging
• Up to 3200W Smart Generator input
• Compact Power Hub combines the main charging, inverter, and conversion components into one unit
• PowerInsight screen and EcoFlow app support system monitoring, energy usage, input viewing, and settings control
• Available AC/DC Smart Distribution Panel with 16 fused DC positions and 12 AC positions

Available Configurations:

• Power Hub + Battery: Core setup with the 5kVA Power Hub and LFP battery storage
• Power Hub + Battery + 30A AC/DC Smart Distribution Panel: Adds organized AC/DC circuit distribution with fused DC and AC positions
• Power Hub + Battery + PowerInsight + 30A AC/DC Smart Distribution Panel: Adds the mounted PowerInsight screen for system monitoring and control

Description:

EcoFlow Power Kits Gen 2 5kVA 48V system provides an integrated power setup for vans, motorhomes, RVs, and compact off grid builds. The Power Hub combines key electrical components into one compact unit, including MPPT solar charge controllers, a DC DC battery charger with MPPT, an inverter charger, and a DC DC step down converter.

With up to 4000W output and 8000W surge power, the system is built to support high demand RV and van appliances, including the ability to run two 13,500 BTU RV air conditioners at the same time. Stackable LFP batteries allow capacity to expand from 5kWh to 45kWh, giving builders room to size the system around short trips, extended travel, or longer off grid use.

For monitoring and control, the system works with the EcoFlow app and PowerInsight screen to view energy usage, check energy input, and adjust settings. The optional AC/DC Smart Distribution Panel adds 16 fused DC positions and 12 AC positions for organized power distribution throughout the RV or van build.
